Pickled Steel

Pickling is a metal surface treatment process that utilizes acids to remove oxide layers and impurities from steel surfaces. This enhances the steel’s surface quality, improving its paint adhesion and welding capabilities.It is widely used in various industries, such as automotive and construction, to ensure high-quality material performance.

Hot rolled flat products made of high yield strength steels for cold forming

Special steels produced by combining controlled rolling with heat treatment. It enhances their strength and ductility, making them ideal for various demanding applications. The key advantage is the improved mechanical properties achieved through microstructural control, which results in a more efficient and cost-effective material suitable for industries like construction and automotive.

Designation of steel grade		C	Mn	Si	P	S	AI total	Nb	V	Ti	Mo	B
Steel Name	Steel Number	% Max	% Max	% Max	% Max	% Max	% Min	% Max	% Max	% Max	% Max	% Max
S315MC	1.0972	0.12	1.30	0.50	0.025	0.020^b	0.015	0.09^a	0.20^a	0.15^a	–	–
S355MC	1.0976	0.12	1.50	0.50	0.025	0.020^b	0.015	0.09^a	0.20^a	0.15^a	–	–
S420MC	1.0980	0.12	1.60	0.50	0.025	0.015^b	0.015	0.09^a	0.20^a	0.15^a	–	–
S460MC	1.0982	0.12	1.60	0.50	0.025	0.015^b	0.015	0.09^a	0.20^a	0.15^a	–	–
S500MC	1.0984	0.12	1.70	0.50	0.025	0.015^b	0.015	0.09^a	0.20^a	0.15^a	–	–
S550MC	1.0986	0.12	1.80	0.50	0.025	0.015^b	0.015	0.09^a	0.20^a	0.15^a	–	–
S600MC	1.8969	0.12	1.90	0.50	0.025	0.015^b	0.015	0.09^a	0.20^a	0.22^a	0.50	0.005
S650MC	1.8976	0.12	2.00	0.60	0.025	0.015^b	0.015	0.09^a	0.20^a	0.22^a	0.50	0.005
S700MC	1.8974	0.12	2.10	0.60	0.025	0.015^b	0.015	0.09^a	0.20^a	0.22^a	0.50	0.005
S900MC	1.8798	0.20	2.20	0.60	0.025	0.010	0.015	0.09^a	0.20	0.25	1.00	0.005
S960MC	1.8799	0.20	2.20	0.60	0.025	0.010	0.015	0.09^a	0.20	0.25	1.00	0.005

a The sum of Nb, V and Ti shall be max. 0.22%

b If agreed at the time of the order the sulphur content shall be max. 0.010% (ladle analysis).

See Clause 11, option 12).

Designation of steel grade		Minimum yield strength R_eH MPa^a,e	Tensile strength R_m MPa^a,e	Minimum percentage elongation at fracture A %^a Nominal thickness in mm		Bending at 180^o minimum mandrel diameter^b,c
Steel Name	Steel Number	Minimum yield strength R_eH MPa^a,e	Tensile strength R_m MPa^a,e	<3 L_O=80	≥3 L_O=5.65√S_o	Bending at 180^o minimum mandrel diameter^b,c
S315MC	1.0972	315	390-510	20	24	0t
S355MC	1.0976	355	430-550	19	23	0.5t
S420MC	1.0980	420	480-620	16	19	0.5t
S460MC	1.0982	460	520-670	14	17	1t
S500MC	1.0984	500	550-700	12	14	1t
S550MC	1.0986	550	600-760	12	14	1.5t
S600MC	1.8969	600	650-820	11	13	1.5t
S650MC	1.8976	650^d	700-880	10	12	2t
S700MC	1.8974	700^d	750-950	10	12	2t
S900MC	1.8798	900	930-1 200	7	8	8t^f
S960MC	1.8799	960	980-1 250	6	7	9t^g

a The values for the tensile test apply to longitudinal test pieces.

b The values for the bend test apply to transverse test pieces.

c t=thickness in mm of test piece for bend test

d For thicknesses > 8mm the minimum yield strength can be 20 MPa^e lower.

e 1MPa=1N/mm²

f Bending at 90°, for thicknesses less than 3 mm minimum mandrel diameter 7t.

g Bending at 90°, for thicknesses less than 3 mm minimum mandrel diameter 8t.
