Aluminium Alloy
Aluminum alloy is a material composed of aluminum and other metal elements
with light weight, high strength characteristics, widely used in industrial and manufacturing fields.
5000 Series
Aluminium and Aluminium Alloy Sheets, Strips and Plates
Aluminum is widely used in the automotive industry. Its lightweight properties can help reduce vehicle body weight, improve fuel economy, and enhance vehicle safety and ride comfort. Aluminum alloys are used in various automotive components, including body panels, engine components, and chassis parts. With continued advances in aluminum alloy technology, the application prospects for aluminum in automotive manufacturing are expected to expand further.
Application: Automobile aluminum alloy sheet and strip
Thickness: ≥0.2mm
Material: A 5052 /A 5182 / A 5754/ EN AW5052/ EN AW5182/ EN AW5754
Width: 980~2450mm
Temper: O/H14/H24/H34
Table 1 Grade, class and symbol
| Grade | Symbol | Informative reference (Characteristics and examples of application) |
|---|---|---|
| 5052 | A 5052 P | A representative alloy having a medium strength. Excellent in corrosion resistance, formability, and weldability. For materials for ships, vehicles, buildings, beverage cans and others. |
| 5182 | A 5182 P | Almost the same strength as that of 5083, excellent in formability and corrosion resistance. For beverages cans others. |
| 5754 | A 5754 P | An alloy having strength between those of 5052 and 5454. |
| Alloy No. | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ga, V, NI, B, Zr, etc. |
Ti | Others Individual |
Others Total |
AL |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5052 | 0.25 max. | 0.40 max | 0.10 max. | 0.10 max. | 2.2 to 2.8 | 0.15 to 0.35 | 0.10 max. | — | — | 0.05 max. | 0.15 max. | Remainder |
| 5182 | 0.20 max. | 0.35 max. | 0.15 max. | 0.20 to 0.50 | 4.0 to 5.0 | 0.10 max. | 0.25 max. | — | 0.10 max. | 0.05 max. | 0.15 max. | Remainder |
| 5754 | 0.40 max. | 0.40 max | 0.10 max. | 0.50 max. | 2.6 to 3.6 | 0.30 max. | 0.20 max. | Mn+Cr 0.10 to 0.6 | 0.15 max. | 0.05 max. | 0.15 max. | Remainder |
| Symbol | Temper grade (2) | Thickness mm |
Tensile strength N/mm2 |
Proof stress N/mm2 |
Elongation(14) % A50mm |
Thickness mm |
Inside radiums |
|---|---|---|---|---|---|---|---|
| A 5754 P | O | 0.2 or over, up to and incl. 0.5 | 190 min. 240 max. |
80 min. | 12 min. | — | — |
| A 5754 P | O | 0.2 or over, up to and incl. 0.5 | 190 min. 240 max. |
80 min. | 14 min. | — | — |
| A 5754 P | O | 0.2 or over, up to and incl. 0.5 | 190 min. 240 max. |
80 min. | 16 min. | — | — |
| A 5754 P | O | 0.2 or over, up to and incl. 0.5 | 190 min. 240 max. |
80 min. | 18 min. | — | — |
| A 5754 P | H24 H34 |
0.2 or over, up to and incl. 0.5 | 140 min. 180 max. |
— | 1 min. | 0.2 or over, up to and incl.9 Over 2.9, up to and incl.6 |
Thickness x 1 Thickness x 1.5 |
| A 5754 P | H24 H34 |
Over 0.5, up to and incl.1.5 | 140 min. 180 max. |
115 min. | 2 min. | 0.2 or over, up to and incl.9 Over 2.9, up to and incl.6 |
Thickness x 1 Thickness x 1.5 |
| A 5754 P | H24 H34 |
Over 1.5, up to and incl. 3.0 | 140 min. 180 max. |
115 min. | 3 min. | 0.2 or over, up to and incl.9 Over 2.9, up to and incl.6 |
Thickness x 1 Thickness x 1.5 |
| A 5754 P | H24 H34 |
Over 3.0, up to and incl. 6.0 | 140 min. 180 max. |
115 min. | 4 min. | 0.2 or over, up to and incl.9 Over 2.9, up to and incl.6 |
Thickness x 1 Thickness x 1.5 |
| A 5052 P | H14 H24 (3) H34 |
0.2 or over, up to and incl. 0.5 | 235 min. 285 max. |
180 min. | 3 min. | 0.2 or over, up to and incl.0.8 Over 0.8, up to and incl.2.9 Over 2.9, up to and incl. 6 |
Thickness x 1 Thickness x 1.5 Thickness x 2 |
| A 5052 P | H14 H24 (3) H34 |
Over 0.5, up to and inlc. 0.8 | 235 min. 285 max. |
180 min. | 4 min. | 0.2 or over, up to and incl.0.8 Over 0.8, up to and incl.2.9 Over 2.9, up to and incl. 6 |
Thickness x 1 Thickness x 1.5 Thickness x 2 |
| A 5052 P | H14 H24 (3) H34 |
Over 0.8, up to and inlc. 1.3 | 235 min. 285 max. |
180 min. | 4 min. | 0.2 or over, up to and incl.0.8 Over 0.8, up to and incl.2.9 Over 2.9, up to and incl. 6 |
Thickness x 1 Thickness x 1.5 Thickness x 2 |
| A 5052 P | H14 H24 (3) H34 |
Over 1.3, up to and inlc. 2.9 | 235 min. 285 max. |
180 min. | 6 min. | 0.2 or over, up to and incl.0.8 Over 0.8, up to and incl.2.9 Over 2.9, up to and incl. 6 |
Thickness x 1 Thickness x 1.5 Thickness x 2 |
| A 5052 P | H14 H24 (3) H34 |
Over 2.9, up to and inlc. 6.5 | 235 min. 285 max. |
180 min. | 6 min. | 0.2 or over, up to and incl.0.8 Over 0.8, up to and incl.2.9 Over 2.9, up to and incl. 6 |
Thickness x 1 Thickness x 1.5 Thickness x 2 |
| A 5052 P | H14 H24 (3) H34 |
Over 6.5, up to and inlc. 12 | 235 min. 285 max. |
180 min. | 10 min. | 0.2 or over, up to and incl.0.8 Over 0.8, up to and incl.2.9 Over 2.9, up to and incl. 6 |
Thickness x 1 Thickness x 1.5 Thickness x 2 |
